Sandvik Coromant 5725805 T-Max® P Turning Insert, ANSI Code: CNMM 543-QR 4235, CNMM Insert, Material Grade: M, P, 543 Insert, Diamond Shape, 16 Seat, Negative Rake, Neutral Cutting, For Use On Stainless Steel and Steel, Carbide, Manufacturer's Grade: 4235
12224041
MFG #: 5725805
$33.60
/ EA
Non-Stock Item
- ANSI Code: CNMM 543-QR 4235
- Brand: Sandvik Coromant
- Chipbreaker: QR
- Corner Radius: 0.047
- Cutting Direction: Neutral
- Finish: CVD-TiCN+Al2O3+TiN Coated
- For Use On: Stainless Steel and Steel
- Hole Diameter: 1/4
- Included Angle: 80
- Inscribed Circle: 5/8
- Insert Size: 543
- Insert Style: CNMM
- ISO Code: CNMM 16 06 12-QR 4235
- Manufacturer: Sandvik Coromant
- Manufacturer's Grade: 4235
- Material: Carbide
- Material Grade: M, P
- Maximum Depth of Cut: 10.7
- Rake: Negative
- Relief Angle: 0
- Seat Size: 16
- Series: T-Max® P
- Shape: Diamond
- Thickness: 1/4
Sandvik Coromant Turning Insert, Series: T-Max® P, CNMM Insert, 543 Insert, Diamond, 10.7 mm Maximum Depth of Cut, 5/8 in Inscribed Circle, 1/4 in Thickness, 16 Seat, Negative Rake, QR Chipbreaker, 0.047 in Corner Radius, 1/4 in Hole Dia, Manufacturer's Grade: 4235, ANSI Code: CNMM 543-QR 4235, ISO Code: CNMM 16 06 12-QR 4235, 80 deg Included Angle, 0 deg Relief Angle, Neutral Cutting, Carbide, CVD-TiCN+Al2O3+TiN Coated, Material Grade: M, P, For Use On: Stainless Steel and Steel
- Excellent surface finish
- Reliable and secure machining, even in roughing applications
- Possibility to optimize by using damped Silent Tools™
Excellent surface finish
Reliable and secure machining, even in roughing applications
Possibility to optimize by using damped Silent Tools™
