EATON

EATON AH7810GD AH7800 3-Phase Industrial Grade Manual Motor Controller Switch, 600 VAC, 30 A, 3, 7-1/2, 15 hp Power Rating, 3PST Contact

AH7810GD MFG #: AH7810GD
$142.74 / EA
Non-Stock Item
  • Actuator: Toggle
  • Amperage Rating: 30 A
  • Color: Gray
  • Contact Configuration: 3PST
  • Country of Origin: MX
  • Dimensions: 4-3/4 in L x 3 in W x 3-1/4 in H
  • Enclosure: NEMA 1
  • Environmental Conditions: -4 to 140 deg F Operating Temperature
  • Manufacturer Name: Eaton
  • Material: Glass Filled Nylon
  • Mounting: Surface
  • Number of Poles: 3
  • Operating Cycles: 30000 Cycles
  • Power Rating: 3, 7-1/2, 15 hp
  • Series: AH7800
  • Terminal Type: Front Wire/Screw/Clamp
  • Type: 3-Phase Industrial Grade
  • Voltage Rating: 600 VAC
EATON Manual Motor Controller Switch, 3-Phase Industrial Grade, Series: AH7800, 600 VAC, 30 A, 3, 7-1/2, 15 hp Power, 3PST Contact Configuration, 3 Pole, Toggle Actuator, NEMA 1 Enclosure, Surface Mounting, Front Wire/Screw/Clamp Terminal, 30000 Cycles Operating Cycles, Glass Filled Nylon, Gray, Environmental Conditions: -4 to 140 deg F Operating Temperature, 4-3/4 in L x 3 in W x 3-1/4 in H Dimensions
QTY
  • Item Features
  • Standards
  • Compact design provides extra wiring room, high impact-resistant, glass filled nylon construction
  • Easy to read electrical ratings on rugged steel mounting straps
  • Highly visible "ON/OFF" markings on large, rugged toggles
  • Distinct wire pockets and thick wall arc barriers prevent strands from straying
  • Screw and clamp or box lug terminals to meet individual project requirements
  • Two sets of contacts per pole distribute load and make/break action for long, reliable duty
  • 3 hp at 120 VAC, 7-1/2 hp at 240 VAC, 15 hp at 480 VAC, 15 hp at 600 VAC
cULus Listed to UL 508, File No. E135083|UL 94-V-0 Flammability Rating|NAFTA Compliant
