Dixon® 50-D-AL Type D Cam and Groove Coupler, 1/2 in Nominal, Female Coupler x FNPT End Style, Aluminum

50-D-AL MFG #: 50-D-AL
$59.40 / EA
Non-Stock Item
Dixon® 50-D-AL Type D Cam and Groove Coupler, 1/2 in Nominal, Female Coupler x FNPT End Style, Aluminum
  • CustomerPartNumber: 100078, 152969
  • Manufacturer: Dixon Valve & Coupling
  • Request For Quote: No
  • Type: Type D
  • Fitting/Connector Type: Coupler
  • Nominal Size: 1/2
  • End Style: Female Coupler x FNPT
  • Length: 2-1/32
  • Pressure Rating: 150
  • Material: Aluminum
  • Brand: Dixon®
Dixon® Cam and Groove Coupler, Type D, Coupling Fitting/Connector, 1/2 in Nominal, Female Coupler x FNPT End Style, 2-1/32 in Length, 150 psi Pressure, Aluminum
QTY
Add to List
  • Precision machined to rigid tolerances
  • Stainless pins will not rust or bind, providing great strength and safety
  • Recess holds gasket firmly in place - ensures proper placement
  • Long shank design allows proper banding, thus eliminating the major cause of hose damage
  • Finger rings are not supplied
  • Under no circumstances should cam and groove couplings be used for compressed air or steam service!
  • Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature
  • 150 psi at ambient temperature 70 deg F pressure
  • Dixon and boss-lock cam and groove couplings do not interchange in the 1/2 in size
  • Warning: this product contains a chemical known to the state of California to cause birth defects or
  • Do not use in connection with drinking water
  • Wash hands after handling
  • 356T6 Aluminum
Precision machined to rigid tolerances
Stainless pins will not rust or bind, providing great strength and safety
Recess holds gasket firmly in place - ensures proper placement
Long shank design allows proper banding, thus eliminating the major cause of hose damage
Finger rings are not supplied
Under no circumstances should cam and groove couplings be used for compressed air or steam service!
Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70 deg F with a standard seal installed
150 psi at ambient temperature 70 deg F pressure
Dixon and boss-lock cam and groove couplings do not interchange in the 1/2 in size
Warning: this product contains a chemical known to the state of California to cause birth defects or other reproductive harm
Do not use in connection with drinking water
Wash hands after handling
356T6 Aluminum
