Proto®

Proto® JSCV14S Reversible Spline Stubby Combination Wrench, 7/16 in, 12 Points, 15 deg Offset, 4 in OAL, Chrome Vanadium Steel, Polished Chrome/Black, ASME Specified

JSCV14S MFG #: JSCV14S
$43.26 / BX
Non-Stock Item
Proto® JSCV14S Reversible Spline Stubby Combination Wrench, 7/16 in, 12 Points, 15 deg Offset, 4 in OAL, Chrome Vanadium Steel, Polished Chrome/Black, ASME Specified
  • Box End Thickness: 19/64 in
  • Box End Width: 55/64 in
  • Country of Origin: TW
  • Finish/Coating: Polished Chrome/Black
  • Manufacturer Name: Stanley Black & Decker
  • Material: Chrome Vanadium Steel
  • Measurement System: Imperial
  • Number of Geared Teeth: 72
  • Number of Points: 12
  • Offset Angle: 15 deg
  • Open End Thickness: 5/16 in
  • Open End Width: 29/32 in
  • Overall Length: 4 in
  • Request For Quote: No
  • Specifications Met: ASME Specified
  • Type: Reversible Spline Stubby
  • Wrench Opening: 7/16 in
  • Wrench Type: Ratcheting
Proto® Combination Wrench, Reversible Spline Stubby, Measurement System: Imperial, Ratcheting Wrench, 7/16 in Wrench Opening, 12 Points, 72 Geared Teeth, 4 in Overall Length, 15 deg Offset, 29/32 in Open End Width, 5/16 in Open End Thickness, 55/64 in Box End Width, 19/64 in Box End Thickness, Specifications Met: ASME Specified, Chrome Vanadium Steel, Polished Chrome/Black
QTY
Add to List
  • Item Features
  • The chrome vanadium switch lever allows for easy changes in turning direction which helps improve speed
  • 15 deg angled offset helps keep shank clear of obstructions
  • Box end is countersunk for easy application to the fastener
  • Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized
  • Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to foreign object damage (FOD)
  • The high contact surface area which is away from fastener points enables turning of highly rounded fasteners
  • Black chrome finish is corrosion-resistant and visually distinctive
  • Compact size allows you to work in tight spots
  • 72-teeth ratcheting mechanism rotates fast with only 5 deg of swing
  • Spline wrenches can be used on 4, 6, 12 point, spline and Torx® fasteners
