Coffing® Hoists

Coffing® Hoists 08210W JLC Single Reeving Electric Chain Hoist With Chain Container, 0.25 ton Load, 10 ft H Lifting, 1/2 hp Power Rating, 115/230 VAC

08210W MFG #: 08210W
$6,565.59 / EA
Non-Stock Item
Coffing® Hoists 08210W JLC Single Reeving Electric Chain Hoist With Chain Container, 0.25 ton Load, 10 ft H Lifting, 1/2 hp Power Rating, 115/230 VAC
  • Brake Type: Multiple Disc Motor
  • Color: White Enamel
  • Control Type: 1-Speed
  • Country of Origin: US
  • Dimensions: 24-1/8 in L x 8-11/16 in W x 8-11/16 in H
  • Headroom: 18-1/8 in
  • Lift Speed: 16 fpm
  • Lifting Height: 10 ft
  • Load Capacity: 0.25 ton
  • Manufacturer Name: Columbus McKinnon
  • Power Rating: 1/2 hp
  • Series: JLC
  • Type: Single Reeving
  • Voltage Rating: 115/230 VAC
  • Weight: 63 lb
Coffing® JLC hook and lug suspension models are designed for industrial duty performance. Compact in size, the JLC features a multiple disc motor brake, overload clutch and chain end stop for safety.
QTY
Add to List
  • Item Features
  • Application
  • Standards
  • Standard push button drop is 4 ft less than lift
  • Limit switches - adjustable to regulate upper and lower load travel
  • Brass nuts standard for improved repeatability and chain positioning
  • Precision machined alloy steel gears run in oil bath for longer, quieter operation
  • NEMA 3R push button station - ergonomic design fits operator's hand for thumb or two handed operation
  • 24 V control for operator safety
  • Frame - compact aluminum housing for portability and ease of installation
  • Chain containers standard on lifts up to 20 ft single chain/10 ft double chain
For industrial applications
CSA Certified
