Grundfos 96160183 SQE Submersible Pump, 2 Wires, 3 Stages, 200/240 VAC, 1 Phase , 11.46 ft Max Suction Lift, 1/2 hp Power Rating
96160183
MFG #: 96160183
Requires Quote
Non-Stock Item
- Amperage Rating: 5.2 A
- Bearing Type: Thrust
- Enclosure Type: IP68
- Flow Rate: 8.81 gpm
- Frequency Rating: 50/60 Hz
- Impeller Type: Floating
- Manufacturer Name: Grundfos
- Material: Stainless Steel
- Maximum Suction Lift: 11.46 ft
- Motor Speed: 10700 rpm
- Number of Stages: 3
- Number of Wires: 2
- Phase: 1
- Power Rating: 1/2 hp
- Series: SQE
- Temperature Rating: 68 deg F
- Voltage Rating: 200/240 VAC
The SQE is the only constant pressure pump on the market fully equipped with built-in electronic controls which allow for advanced computer controlled performance and state of the art protection features including sophisticated diagnostics. The motor design is a variable speed drive which electronically changes the pump speed to match demand providing you with the incredible comfort of constant pressure.
- Item Features
- Application
- Includes
- Standards
- Warranty
- Soft start - Prevents water hammer and motor overheating
- Dry run protection - Pumps are water lubricated and if your well runs low, an unprotected pump will die
- Overload protection - If a pump becomes clogged with debris like sand or grass, it can destroy an unprotected motor
- Over and under voltage protection - The lifetimes of unprotected motors can be greatly reduced by improper voltages
- Push button pressure set point adjustment
- Low well water indicator
- Pump running indicator
- Keypad lockout
- High quality stainless steel pressure sensor
- Built-in diagnostics
- High pump and motor efficiency
- Wear resistance
- Basic version with electronic communication
Domestic Water Supply, Ground Water Supply, Light Commercial, Irrigation and Tank Applications
84Z04953 MSE3 Stainless Steel Motor
AISI 304|cUL/UL Listed
Limited
