Schneider Electric TeSys™ LC1D25G7 D-Line IEC Contactor With Protective Cover, 120 VAC V Coil, 25 A, 3NO Contact, 3 Poles

LC1D25G7 MFG #: LC1D25G7
$227.82 / EA
Non-Stock Item
Schneider Electric TeSys™ LC1D25G7 D-Line IEC Contactor With Protective Cover, 120 VAC V Coil, 25 A, 3NO Contact, 3 Poles
  • CustomerPartNumber: 101067, 101079, 101110, 126261
  • Manufacturer: Schneider Electric
  • Type: D-Line
  • Coil Voltage: 120
  • Maximum Load Current: 25
  • Coil Power Rating: 70 VA Inrush/7/7.5 VA Hold-In
  • Number of Poles: 3
  • Frequency Rating: 50/60
  • Wattage: 11
  • Contact Type: Non-Reversing
  • Contact Configuration: 3NO
  • Number of Auxiliary Contacts: 1NO/1NC, 1NO-1NC
  • Power Factor: 0.75 Inrush/0.3 Hold-In
  • Connection Type: Screw Clamp
  • Terminal Type: Screw Clamp, Screw/Clamp
  • Enclosure Type: IP2X
  • Operating Cycles: 15, 15 MCycles
  • Operating Temperature: -5 to 60
  • Mounting Type: Plate/Rail
  • Dimensions: 85 mm H x 45 mm W x 92 mm D
  • Brand: Schneider Electric
  • Terminal: Screw Clamp
Schneider Electric TeSys™ IEC Contactor, D-Line, 120 VAC Coil, 25 A Maximum Load Current, 70 VA Inrush, 7/7.5 VA Hold-In Coil, 3 Pole, 50/60 Hz Frequency, 11 kW Wattage, Non-Reversing Contact, 3NO Contact Configuration, 1NO-1NC Auxiliary Contacts, Power Factor: 0.75 Inrush, 0.3 Hold-In, Screw Clamp Connection, Screw Clamp Terminal, IP2X Enclosure, 15000000 Cycles Operating Cycles, -5 to 60 deg C Operating, Plate/Rail Mounting, 85 mm H x 45 mm W x 92 mm D Dimensions
QTY
Add to List
  • Without built-in bidirectional peak limiting diode suppressor coil technology
  • IP2 x IEC 60529
Without built-in bidirectional peak limiting diode suppressor coil technology
IP2 x IEC 60529
